25 Tons Cleaning Truck: A Smart, Sustainable Solution for Urban Sanitation

As cities continue to modernize, the demand for reliable, high-performance sanitation equipment is greater than ever. The 25 Tons Cleaning Truck, a pure electric vehicle built with advanced environmental technology, offers a powerful and sustainable solution for large-scale urban cleaning tasks. Designed for flexibility and equipped with modern features, this vehicle stands out as an intelligent choice for municipalities and industrial parks alike.

One of the truck’s most distinctive features is its independent low-pressure cleaning system. This system includes front duckbill flushing, front counter-flush, rear sprinkling, and a water cannon assembly, allowing it to meet various urban cleaning needs with precision and efficiency. Depending on specific user requirements, the vehicle can also be equipped with optional functions such as spray systems, greening irrigation, low-pressure reel flushing, and high-pressure reel flushing. These additional functions make the truck suitable not only for road cleaning but also for tasks such as urban landscaping and tunnel maintenance. However, it is important to note that this cleaning system is not suitable for cold or freezing conditions, as low temperatures may affect its performance or lead to freezing of internal components.

The truck rides on a dedicated pure electric chassis developed by Geely Sichuan Commercial Vehicle Co., Ltd. This platform is engineered for durability, strong carrying capacity, and excellent energy efficiency. It is designed to support prolonged daily use in high-demand urban settings. The vehicle is powered by the TZ488XSPE352WH permanent magnet synchronous motor produced by Dana (Beijing) Motor Co., Ltd. This motor has a protection level of IP67, offering high resistance to dust and water. It delivers exceptional performance, with an impressive output efficiency of up to 95%, a peak power of 350 kW, and a maximum torque of 3500 Nm. These characteristics ensure strong acceleration, reliable operation under load, and long service life, even in rigorous working conditions.

The electronic control system is also provided by Dana (Beijing) Motor Co., Ltd., and it is built with safety and reliability in mind. The controller, also rated at IP67, features integrated protection against overvoltage, undervoltage, overcurrent, and overheating. This intelligent design ensures that the electrical system remains stable and secure throughout the truck’s operation, significantly reducing the risk of downtime or component failure.

Powering the vehicle is a battery system composed of lithium iron phosphate batteries manufactured by Ningde Times New Energy Technology Co., Ltd. These batteries are known for their superior thermal and chemical stability. To ensure safety and durability, the battery system has undergone a comprehensive series of tests, including vibration, impact, extrusion, wet and hot cycles, seawater immersion, exposure to external fire, and overtemperature protection. With a protection rating of IP68, the battery system is fully sealed and can withstand exposure to water and dust, providing operators with peace of mind during challenging environmental conditions.

The cleaning truck also features a large-capacity water tank, which enhances its productivity by reducing the need for frequent refills. The total volume of the water tank is 12.81 cubic meters, with an effective volume of 10.4 cubic meters. Designed using finite element analysis (FEA), the tank structure has been optimized for strength and reliability. The tank is manufactured using advanced one-time canning molding technology and undergoes permeable non-destructive testing to ensure that it remains leak-proof even under long-term use. The interior of the tank is coated with a specialized epoxy coal tar paint that offers superior resistance to corrosion, greatly extending the lifespan of the water system.

In summary, the 25 Tons Cleaning Truck brings together cutting-edge electric drive technology, intelligent cleaning functions, and robust safety features to create a reliable and future-ready sanitation vehicle. From its highly efficient powertrain to its custom-configurable cleaning system and durable water tank, this vehicle is designed to meet the growing demands of urban environments while supporting green, sustainable development goals. It is not just a cleaning truck—it is a modern urban solution built to last.
